Auto-adaptation 10mbps and 100mbps, convenient for network updating With distinct ic ip113 hic solution, low-temperature-rise chip, no need of cooling system, realization of flow control, decrease of broadcast storm With famous brand optical-electronic-integration module providing excellent optical and electrical properties to ensure reliable data transmission and long working life¬~speed 10/100m Supporting broadcast filtering, address auto-learning and auto-updating, and store-and-forward operating mechanism Supporting full-duplex flow control or half-duplex back pressure working pattern, along with auto-negotiation Single rj-45 electrical port nic/hub, auto cross-identification, link to computer network cards or switches or hub Supporting the switches to choose between 10/100mbps store-and forward and straight-through transmission pattern(distinct) Supporting 1600byte super data packet transmission Providing indicator lamps for link-loss, electrical and optical link diagnosing, dynamic data transmission and full/half duplex, data rate With more than 50, 000 hours mtbf, complying with telecom operating standard Ultra low power dissipation(< 2.5w, input:ac140 ~ 260v), low heat, long-time stable work Supporting choosing optical ports from dual fiber(mm), dual fiber(sm), single fiber(sm). Normal package
Ethernet switch Complies with ieee802. 3 10base-t, ieee802.3u 100base-tx. Store and forward 111function. Full or half duplex, Plug and play installation with automatic port configuration 24 10/100m self-negotiable rj-45 ports, auto-shift 10base-t and 100base-tx. Basic board width: 4.8 gbps, supply separate board width for each port to 111realize real bon-blocking transmission Store-and-forward Built-in 4m bit data buffer, supply full forwarding rate 19" standard rack-mounted size Power: 90-240vac·+50-60hz Operation temperature: 0 ~ 50 f¦ Store temperature: -20 ~125 f¦ Operation moisture: 10~90% Store moisture: 5~90% Size: 440*177*44 mm Weight: 3.5kg (with packing)
Ethernet switch Complies with ieee802.3 f=ieee 802.3u ieeef=802.3xf=802.1p Store and forward function. Full / half duplex mode Plug and play installation with automatic port configuration 16 10/100m self-negotiable rj-45 ports, 1 uplink port. Auto-shift 10base-t 111and 100base-tx. All ports support ieee802.3x full duplex flow control, and half duplex 111back-pressure flow control Basic board width: 3.2 gbps, supply separate board width for each port to 111realize real bon-blocking transmission 4k mac address Switch led indicator: 1 led (power) Port led indicator: 2 leds (link & 10/100mbps) Power: 100-240vac·+50-60hz Operation temperature: 0 ~ 40 f¦ Store temperature: -20 ~70 f¦ Operation moisture: 10~90% Store moisture: 5~90% Size: 440*177*44 mm
Specification Specification: 1.Specification: 4p+mylar+al+b 2.Rated temperature: 60¡ãc or 75¡ãc 3.Unshielded twisted pairs: 4.Conductor: 26awg or 24awg stranding or solid bare copper 5.Insulation: hd-pe 6.Inner shielded: al-mylar 100%(min) coverage 7.Outer shielded:tinned copper or al-mg braid 45%(min) coverage 8.Unrip rope:optional 9.Jacket: pvc or lsnh 10.Impedance:100¡à15%¦¸ at 1~100 mhz 11.Reference standard: yd/t1019-2001, iso/iec11801, ansi/tia/eia-568b, ul 444 12.Print legend: cm or cmr Features 1. Solid copper conductor allows high speed of signal transmission 2.Fast and reliable connection 3.Twisted pairs with bright color for easy recognition 4.Ripcord and footmark for convenient use 5.Smooth jacket for easy pulling in tight space 6.Color in light grey, dark grey, blue, white or as per your requirement Application 1.Computer network cabling project 2.Broadband network communication 3.Digital isdn network and atm 155mbps network 4.Ethernet network 5.Audio and data transimission Packing: 1) packing length: 100m/roll, 200m/roll, 305m/roll, 100yard/roll, 200yard/roll, 300yard/roll. 2) inner packing: wooden reel, plastic reel. 3) outer packing: carton box, pull out box, pallet available. 4) other packing available according to client's request. Port: shenzhen Minimum order quantity: 99 roll/rolls Supply ability: 50000 roll/rolls per day Payment terms: l/c, t/t
OCS1 Ethl 00 FX with external optical interface can be atmospheric insert into an existing fibre communication line without any additional modifications (passing obstacles) as it is a conveyer of the optical radiation (two fiber 1300 nm, or one fiber 1300/1550 nm). OCS1 Eth100 TX can be a terminal device with external interface 100Base-TX and directly provide connection of two computers or two local area networks. Delivery set • Transceiver Optical Unit OU with pointing device-2 units • Tooling column with the elements of prealignment-2 units • Optical-electrical converter-2 units • Fiber-optic cable(10 meters)-2 units. Cable lenth might be increased up to 100 meters(option) Transmission standards IEEE.802.3/FastEthernet Data transmission speed 100 Mbps Transmission method - Infrared emission Wavelength 800-870nm Average radiation power 100mW Threshold sensitivity -30dBm External interface 100Base-FX/Sc1310/1550, 100Base-TX Recommended operating distance Up to 1500m Operating regime - Continuous Time between failures - 100000 hours Input power supply - 220V ±10%,50Hz Accumulator power supply,(optional) 12V Power consumption Up to 6W Operating temperature range: From -50C to+50C Relative air humidity: Up to 100% Interface cable length TX-100meters,FX-20000 meters Interface fiber optics cable length Up to 100m Scope: Internet-providing, enterprise customers. Packaged in box, size: 600*500*350 mm. Weight 33kg.
OCS2-Ethernet 100 is a fast and reliable solution. The solution is convenient from the point of view of installing the system into already existing net due to flexibility of the technical solutions used in the design of this device. Economy modification OCS2-Ethernet100 is intended to organize wireless broadband connection in local and corporate networks. It solves the tasks of local area networks connection in the shortest time and at moderate price. Recommended communication range is 800m. Delivery set • Transceiver Optical Unit OU with pointing device-2 units • Tooling column with the elements of prealignment-2 units • Optical-electrical converter-2 units • Fiber-optic cable(10 meters)-2 units. Cable lenth might be increased up to 100 meters(option) Transmission standards IEEE.802.3/FastEthernet Data transmission speed 100 Mbps Transmission method - Infrared emission Wavelength 800-870nm Average radiation power 100mW Threshold sensitivity -30dBm External interface 100Base-FX/Sc1310/1550, 100Base-TX Recommended operating distance Up to 1500m Operating regime - Continuous Time between failures - 100000 hours Input power supply - 220V ±10%,50Hz Accumulator power supply,(optional) 12V Power consumption Up to 6W Operating temperature range: From -50C to+50C Relative air humidity: Up to 100% Interface cable length TX-100meters,FX-20000 meters Interface fiber optics cable length Up to 100m Scope: Internet-providing, enterprise customers Delivery set Transceiver Optical Unit OU1 with pointing device - 2 units; Tooling column with the elements of prealignment- 2 units; Optical-electrical converter - 2 units; Fiber-optic cable (10 meters) - 2 units. Might be erased up to 100 meters - option. Packaged in Box: 600*500*350 mm. Weight 33kg
Deliver Power up to 328ft (100m) Plug and Play installation Max 30W output power Simplified the installation of Ethernet based devices Compliant with IEEE802.3at Auto Detection and protection of non-standard Ethernet terminal . 20pcs/Carton.
Deliver Power up to 328ft (100m) Plug and Play installation 8 ports PoE Simplified the installation of Ethernet based devices Auto Detection and protection of non-standard Ethernet terminal Pass Through Data Rates : 8-Port 10/100 Mbps. 5pcs/Carton.
-10/100M self-adaptive Ethernet Interface -Support ATUO MDI/MDIX, allowing crossover cable connection or straight-through cable connection -Selectable Baud rate between 1299bps and 921.6Kbps -Build-in WEB server, allowing users to configure their webpage easily -Auto reconnection after a network break, ensure the reliable TCP connection for the whole network -Support DNS, can achieve a communication using the domain name -Compatible to SOCKET working modes (TCP Server, TCP Client, UDP and etc.), the upper layer machine software is written strictly following the SOCKET rules -TCP modes supports multi connections, specific data sending after password verifying, allowing up to 4 user to manage a single embedded device at a same time -Advanced security mechanisms, prevent illegal access from unauthorized visitors, provide IP verifying firewall, and up to 8 configurable IP or IP segment certifications -Support the local and remote upgrading of the firmware;Support AT Command configuration;Support remote configuration -16 bits ARM7 CPU; -Ethernet: 10/100Mbps -Protections: build-in 2KV surge protection -Type:RS232, RS485 -Control Signals :TXD,RXD,GND -Parity: None, Even, Odd -Data Bit: 5, 6, 7 or 8 bits -Stop Bit: 1 or 1.5 bits -Flow Control: Non -Baud Rate: 1200bps~921.6Kbps -Compatible Protocol: Ethernet, ARP, IP, UDP, TCP, BootP -Network Services: DHCP, DNS, PPPoE, TFTP, HTTP, UDP Broadcasting -Client/Server: Server -Ethernet Connector: RJ-45 -Ethernet Speed/Duplex: Auto-negotiation 10/100Mbps, Full/Half duplex -Auto-MDIX: Yes -WOL: Magic Packet, Wakeup Frame, Link-Up events -Software Tool: VSP Driver, DS Manager, Web Server -Configuration Mode: Web browser configuration tool, Windows Hyper Terminal, Telnet, Serial port configuration -Power Input: 3.3V DC -Physical Size (Wí-Dí-H): 77.5í-41.7í-22.7(mm)
Ousentí»s WDM(Bi-direction) Fast Ethernet SFP -Operating data rate up to 155Mbps -Distance from 20km to 120km -Single 3.3V Power supply and TTL Logic -Duplex LC Connector Interface -Hot Pluggable -Operating Case Temperature: Standard: 0C~+70C, Industrial: -40C~+85C -RoHS, CE, FDA, FCC certificates, -Compliant with MSA SFP Specification -Digital diagnostic monitor interface Compatible with SFF-8472 Compatible with other manufactures SFP+ (SFPplus) transceiver: Cisco GLC-FE-100BX-D, GLC-FE-100BX-U 3Comú¼ Huawei, Foundry, Juniper, Extreme, Nortelí¡.. P/N Detailed Description Form Data Rate Tx(nm) Pout (dBm) Rx Se (dBm) Connector DDM Reach BIDI íí 100BASE BIDI SFP-LC without DDM (Fast Ethernet) OST-100BX-S35-20 SFPBI 100/155M 1310nm FP -14~-8 1550PIN
The mb-ecb is one passive ethernet transmission that can transmit 10 base-t ethernet signal over one coax cable up to 642ft(196m).It allows any cctv ip camera or other ethernet devices to be connected within extended distance without power .With super interference rejection and high-end tvs for surge protection, mb-ecb can protect device from damange.In any harsh electrical areas.The device is often used in legacy installations where existing cable is re-deployed as part of an upgrade to ip cameras or other ethernet devices.Mb-ecb work in pairs .The transmission is extremely simple to use , with no ip or mac addressing required.
V-rebplus is a 10/100m, self-adaptive, high performance, self-learning, remote ethernet bridge. Its low cost make it suitable for cost-sensitive bridging application or as a lan extender or subsection. When it is used as a extender or subsection, it can forbid filtrating to let all of the amount of traffic are transmitted in wan. Its 10 base-t interface can run in full duplex ethernet with topology and improve data throughput by eliminating the padding bit in 64 bytes frame. Variable speed up to 10mbps on the wan line is supported transparently. The line rate may be adjusted in running without any influence to v-rebplus. V-reb plus does not perform any negotiation over the link, which is specially suitable for satellites and other wireless broadcast applications. Features: *10/100m high fast powered self-adapting self-educated long-range ethernet bridge. * lan according with: ieee802.3/ieee802.3u/ethernet interface: utp(rj45) * wan interface: v.24/rs232 & v.35 optional * wan line speed rate reaches up to 10mbps. * speed of filtrating and transmitting is up to 30000 frame/ second. Buffer is 16m. * it can store up to10000 mac. And mac addresses have functions of automatically learning and updating. * ethernet utp interface has function of vlan802.1q. There have two transmitting mode to choose: data and image. * automatically learn mac addresses on the lan to which it is connected, and forward only those frames destined for another lan. Carton.
Single color 1536*64, dual color 384*128; LS-T3 we offer serial port, USB port, Ethernet port three versions for your option; Scanning mode:1/16,1/8,1/4,1/2, static routing Scanning interface: 50PIN interface Communication mode: RS232, RS485, USB,100M NET Port Wireless communication: Support GSM, GPRS, RF Memory: 2M Bytes Extended interface: Temperature sensor, test button, switch Player: LED Player 3.1 Static bag, carton 0.5kg/pcs
Features: -Broadcast filtering, address auto learning and auto-update feature and th operating mechanism of store and forward. -Cache size: 256KB, address table size: 4KB -Ethernet 10Base-T or 100Base-TX or 1000Base-T to 1000Base-LX fiber optic media converters -Support IEEE 802.3, IEEE 802.3U, IEEE 802.3X, IEEE 802.3z/AB, IEEE802.1d -Supports full-duplex or half-duplex backpressure flow control flow control, and with Auto-Negotiation function -Interface supports 1000Mbps, 100Mbps, 10Mbps, can use with notthe same rate. -TX/RX dual-header Standard SC interface -Electronical interface supports 10Mbps, 100Mbps, 1000Mbps -Automatically adapt , optical interface work rate 1000Mbps port -Integration of high-quality photovoltaic modules to provide good optical properties and electrical properties to ensure reliable data transmission -Status LEDs on link/connection status, dynamic data transfer/ full duplex / half duplex/rate status. -Provides one RJ-45 interface supports auto-electrical cross connect switches, hubs -Power Consumption: 4.5 W (Power adapter input AC-85V~ 265V) -Over 50,000 hours consistent working period. Transmission fiber: Multi-mode: 50/125, 62.5/125 or 100/140166;204;m Single-mode: 8.3/125, 8.7/125, 9 / 125 or 10/125166;204;m Operating temperature :0-50 161;227; C Storage temperature: -40-70 161;227; C Humidity: 5% -90% non condensing.
Free Space Optics OCS equipment was made to give our costumers a great opportunity to create a high speed connections without wires and cables, in a very short period of time and minimise expenses. It's based on transmission data through the IR invisible laser channel for the distances up to 3 kilometers. FSO system allows you to create a wireless channel up to 1.25 Gbps transmission rate, in any weather conditions, in a day without licencing and no negotiations with a landlords. This technology gives a great opportunity to create a high speed connections without wires and cables, in a very short period of time and minimise your expenses. The new model OCS-1 Gigabit Ethernet 1550 is intended for organization of broadband connection in local corporate, house communication systems (Internet, IP-telephony, IP-TV) at the distances up to 1500 m. Technical characteristics Transmission standards Gigabit Ethernet Data transmission speed 1,25 Gb/s Radiation power +10 dBm (10 mW) Wavelength 1500-1550 nm Transmission method Infrared emission Sensivity at the speed of 1 GBps -25 dBm Recommended operating distance Up to 500meters Radiation divergence 0,5 – 2 mrad Maximum operating range 10000 meters Interface G-Ethernet LX (.TX) Power consumption Up to 20W External block desigjn all-weather IP 65 Operating temperature range -50C…...C +50C Fiber optic connection cable length Up to 20m Antenna dimensions (l*w*h) 400*120*350 mm Antenna weight 10 kg Converter unit dimensions(l*w*h)300*320*120 mm Converter unit weight 5 kg. Delivery set Optical unit OU2 -155 – 2 units Optoelectronic converter OEC2G-UO – 2 units Fiber-optic Cable FOC, 10 m – 2 units Fiber-optic Cable FOC, 10 m – 2 units.
Overview Handheld Portable Gigabit Ethernet Tester This handheld Gigabit Ethernet tester is used for the installation and maintenance of 10M/100M/1000M Ethernet. Its functions include network testing, data packet capture, traffic generation, cable testing and BER testing. The Ethernet tester is widely used in BER testing of layer1, layer2, layer3, and RFC-2544. Key Features Handheld Portable Gigabit Ethernet Tester Ergonomic design and easy to carry Jacket cover, tie-in protection, lanyard, hands-free viewing 4.3 in LCD color touch screen, smart navigation menus Results can be shown as texts or graphics 128 sites full line rate 10/100/1000 Mbps traffic transmission RFC2544 automated test, fast network testing and fault location LED indicator, LCD display Large capacity memory for storage of settings and results Online upgrade of firmware Basic Functions Handheld Portable Gigabit Ethernet Tester Full RFC2544 benchmark testing: throughput, frame loss rate, latency and back-to-back Single and multiple site traffic generation Compatible with VLAN tag Connectivity testing: PING, TRACE, ARP SCAN. Conducts termination mode test and frame length, frame type and used ratio status Optical power test and optical module temperature, working current and voltage test Cable VCT: capable of identifying short circuit, open circuit, cable length. Interruption time test Provides test tools including port positioning, packet capture, loopback. Provides external USB drive for data exchange Includes Test Manager Pro software for data management.
Deliver Power up to 328ft (100m) IEEE802.3af Standard compliant Plug and Play installation Output Voltage selectable (5/9/12V) Simplified the installation of Ethernet based devices. Enable the non-PoE devices get power from PoE Switch.
Stand alone Managed 10/100/1000Base-Tx to 10/100/1000Base-Fx Media Converter SUN Telecoms stand alone Ethernet Media Converter is offers a cost-effective product to transmit distances up to 120km (Single-mode fiber). It makes it easy to incorporate the advantages of fiber-based connection technology in a managed Ethernet/Fast Ethernet network. Integrated Auto Cross-over MDI/MDI-X and NWay capabilities make it simple to deploy within a network. Also, the í¦hot-swappableí¦ design is ideal for scaling the system up or down quickly. Features: Web, SNMP, Console management Hot-swappable module Available with ST, SC, or WDM Simplex SC single-fiber connectors Auto MDI/MDI-X on copper port Auto-negotiation on copper port LED status for Link/Activity, LFS, 100, Loopback, and Full Duplex/Collision Link-Fault Signaling illuminates to indicate link failure Link-Fault Signaling function can boot up redundant link if network is installed with primary and redundant link Local and remote loopback
Haishuo ha7000 series epon (ethernet passive optical network) equipment is network product suitable for supplying high-speedf=wide overlay fiber access network. Ha7000 series put the ethernet technology apply to network which can decrease network establish cost, improve network establish efficient. Due to this kind of products adopt ethernet passive optical network technology, it greatly decrease the network establish cost of offering fttb (fiber to the house). It consists of ha7100 series olt equipmentf=ha7200 series onu (optical network unit) and odn(optical distribute network). Ha7100, developed by haishuo technology co., ltd·+is large olt equipment with rack structure. It can cooperate with ha7200 series remote equipment (onu) to form an epon connect through fiber and passive optical distribution network (odn), supporting maximum 8 pon systems. Ha7100 series adopts 19-inch width and 3u height rack with 16 slots among which every two is offered to one olt module, supporting maximum 8 olt module cards. It has a concentrated power supply with active and standby power system, supporting automatic switching. It has five mail functions: large capacity and long transmit distancef=high qosf=flexible dynamic bandwidth allocationf=powerful oam traits and perfect network management function. Ha7200 series include 2 types of onu-ha7200 and ha7200g. The former has a 10/100 auto-adapted electrical interface, and the later a 10/100/1000mbps one. It has four main features: wide coverf=flexible dynamic bandwidth allocation (dba) functionf=perfect network management systemf=simple telnet maintenance Box
Overview: GVE-Tplus is E1 to V.35/V.24/RS232 and Ethernet Converter. Other series interface RS449/RS530/X.21 also can be optional. E1 port can support BNC/75ohm and RJ45/120ohm optional. This device provides an economical digital access solution for E1 and fractional E1 network services. With a adapter cable, the device can connect to other DTE device, such as router, at data rates of 64Kbps to 2048Kbps.User data is placed into the E1 frame, using only the required number of timeslots, timeslot assignment is accomplished according to the data port speed and manual setting of DIP switches. The V.35 or V.24/RS232 and Ethernet share the 2Mbps bandwidth, the total bandwidth of the 2 interfaces must be not more than 1984Kbps.GVE-Tplus is widely used in communication network, both in WAN and LAN connection field. Features: *Comply with ITU V.35, G.703, G.704, G.706, G.823 *Full comply with IEEE 802.3 /IEEE 802.1Q (VLAN) *Framed (N*64Kbps) and unframed (2.048Mbps) optional *Ethernet port 10Mbps, Full/Half Duplex mode compatible *Frame mode support PCM30/PCM31 *Support CRC4 *Support internal clock, E1 recovery clock or V.35 line clock *Provide analog and digital loopback and remote digital loopback test *For E1 interface, 75ohm (unbalanced) and 120ohm (balanced) optional *For data interface, V.35 and V.24/RS232 optional *Comprehensive LED indicators on front panel, convenient for the diagnosis of equipment working state *Stand-Alone and Rack-Mount available *16-slots, elaborate cooling design and two redundant power supplies *Support management *-48V DC & 220V AC power supply optional Specifications: E1 & FE1 interface Comply with ITU G.703,G.704,G.706,G.823 Rate:2.048Mbps;N*64Kbps(N=1~31) Code type:HDB3 Impedance:75ohm unbalanced & 120ohm balanced optional Physical interface:BNC coaxical for unbalanced RJ45 twisted pair for balanced Ethernet interface Comply with IEEE 802.3/IEEE 802.3Q(VLAN) Rate:10Mbps,Half/Full auto-negotiation MDI/MDI-X optional Physical interface:10 Base-T(UTP);RJ45 V.35,V.24/RS232 interface Comply with V.35,V.24/RS232 standard Rate:2048Kbps;N*64Kbps(N=1~31) Transmission mode:Synchronization Data interface:V.35 or V.24/RS232 Physical interface:DB25 female jack,V.35 via external adapter Work mode:DCE Power supply AC power:220V¡¨¤10%,50Hz DC power:-48V(optional) Power:5W Environment Temperature:0¡«40¡æ Humidity:0¡«95% RH Carton.
