CNC Tube Bending Machine NBM38R2-4A
Configuration: Servo Motor: Yaskawa (Japan)
CNC Control System: Dynapath PC Base (USA)
15 inch colorful touch screen:Dynapath (USA)
Reduction Gear: Spinea (Slovakia)
High Bearing :NSK (Japan)
Linear Guide : PMI (China Taiwan)
3D simulation ( Option)
Operation Language: English
Control System

· Windows XP or above operating system, fast and stable.

· CNC tube benders adopt PC-Based control system which offers graphic interface, quick conversion, easy

operation and max. flexibility instead of PLC control system.

· Built-in big capacity USB backs CNC tube benders bending data up automatically whenever machine is

turned on to prevent from unpredictable data loss.

· 10�/12�/15�/17� LCD touch screen with high resolution in CNC tube benders offers big icons and clear

display.

· USB ports provide convenient access of peripheral devices.

3D Simulation / Software Function

· 3D Tube Simulation installed in CNC tube benders can immediately display 3D tube shape based on input data of Y.B.C program. It assists users in editing a correct program and prevents from mistakes effectively.

· 3D Tube Simulation could be real-time shown on the screen while working in semi-auto or fully-auto bendingoperation.

· 3D tube graphic & Tooling dimension data can be previewed in advance that brings users convenient & quick files categorizing and storing as well as data searching.

With over 20 years of international experience, AH Machinery supplies a wide range of top-quality machinery made in Taiwan, including Rotary Draw Banders, Tubular Component Bending, Rolling Draw Benders, Roller Bender Machines, Pipe Bending Machines, Tube Bending Machines, Pipe and Tube Fabrication Equipment, Electric Tube Benders.
Customized specifications are available to meet your unique needs.

/SPECIFICATION/
- Sheet Metal Thickness [mm/inch]= 1/0.04, 1.5/0.06, 1.8/0.07, 2/0.08, 2.5/0.10, 2.6/0.10, 2.77/0.11, 2.9/0.12, 3/0.12, 3.2/0.13, 3.5/0.14, 4/0.16, 5/0.20, 5.48/0.22, 6/0.24, 7/0.28, 8/0.31, 9/0.35, 10/0.39, 12/0.47, 15/0.59, 20/0.79, 25/0.98, 30/1.18, 32/1.26, 35/1.38, 40/1.57, 42/1.65, 45/1.77, 50/1.97, 55/2.17, 60/2.36, 70/2.76, 80/3.15, �¦10, �¦15, �¦20, �¦30, �¦35, �¦50, �¦60, UPN100, UPN120, UPN140
- Min. Diameter [mm/inch]= 200/7.87, 250/9.84, 280/11.02, 300/11.8, 350/13.78, 380/14.96, 400/15.75, 450/17.72, 500/19.69, 550/21.65, 600/23.62, 650/25.59, 700/27.56, 800/31.50, 850/33.46, 900/35.43, 1000/39.37, 1200/47.24, 1300/51.18, 1400/55.12, 1600/62.99, 2000/78.74
- Range of Bending Speed [m/min]= 5, 6, 7
- Diameter of Top Shaft [mm/inch]= 65/2.56, 80/3.15, 100/3.94
- Diameter of Lower Shaft [mm/inch]= 50/1.97, 70/2.76, 100/3.94
- Sheet Metal O.D. [mm/inch]= 10/0.39, 12/0.47, 12.7/10.5, 15/0.59, 20/0.79, 25.4/1, 25/0.98, 30/1.18, 32/1.26, 35/1.38, 40/1.57, 45/1.77, 50.8/2, 50/1.97, 6.35/0.25, 60/2.36, 65/2.56, 70/2.76, 76.2/3, 80/3.15, 100/3.94, 120/4.72, 125/4.92, 139.7/5.50, 140/5.51, 150/5.91, �¦10, �¦15, �¦17.2, �¦20, �¦25, �¦30, �¦35, �¦50, �¦60, �¦76.1, �¦100, UPN100, UPN120, UPN140
- Sheet Metal Height [mm/inch]= 2/0.08, 3/0.12, 4/0.16, 5/0.20, 6/0.24, 7/0.28, 8/0.31, UPN100, UPN120, UPN140
- Main Motor [HP/kw]= 4/3.0, 5.5/4.1, 10/7.5
- Weight [Kgs/Lbs]= 1100/2425, 1700/3748, 3650/8047
- Overall Dimensions [mm] [LxWxH]= 1200x850x1200, 1450x1000x1400, 1465x2000x1700
- For= Light / Heavy Duty
- Type= Profile, Section, Rotary Draw Bander
- Shape= 1 - 18 Type

/FEATURES/
#Customized_specifications_are_available.
#High_caliber_and_Accurate.

/APPLICABLE METERIALS/
Conduit Tubes, Fumiture Iron Pipe, Gas Tubes, Hard Copper & Aluminum, Hydraulic Steel ST35, Mepla, Geberit & Similar Tubes, Mild Steel [EN:S275JO], Soft Brass, Soft Copper, Stainless Steel AISI304-316, Stainless Steel AISI308, Standard Steel Tubes.

/APPLICATIONS/
Automotive Manufacturing Industry, Aerospace Industry, Furniture Production Industry, HVAC Systems, Shipbuilding Industry, Oil and Gas Industry, Construction Industry, Metal Fabrication Industry, Plumbing and Pipefitting, Automotive Exhaust Systems, Marine Industry, Automotive Manufacturing, Aerospace Industry, Medical Equipment Manufacturing.

Welcome to contact us!
A Homia will satisfy you as long as you give us a try.
Contact us today for high-caliber and accurate machinery solutions.

1.Semi-Automatic Tube Bending Machine
Tube Bending Machine
Model: SB-38NC
Max. Bending Capacity: ￠38.1 (1.5�??)�?2mm
Bending Degree: 0-190°
Bending Radius: 20-200mm (for machine)
Min Bending Radius: R�?�1.5D (for pipe)
Mandrel Length: 2000mm(can be customized)
Max. Bending Speed: 90°/s
Bending Accuracy: ±0.1°
Motor Power: 4 Kw
SLS Semi-automatic tube bending machine has an NC control unit to allow the operator to program the bend degree (C axis)-the standard memory can store up to 16 programs each with 16 sequential bends.This allows the operator to select from the memory to bend sequence they require and load the tube and start bending. The rotating and feeding (B&Y axis) are controlled manually. Other movements as die working,mandrel working are controlled by hydraulic. Pipe Bending Machine combines easy-to-use operation with high bending accuracy and cost effectiveness. It is the practical semi-automatic solution for small to medium productions.
STANDARD
Bending Axis-by Hydraulic ,Feeding Axis-by Manual,Rotating Axis-by Manual.
Human Interface offers easy access to auto and manual operating modes.
Fully hydraulic movement on clamp die,pressure die and mandrel.
Available pipe material: steel, stainless, aluminum, titanium and brass...
Available pipe shape: Round,Square,Rectangle,Oval,Solid Bar,other profiles...
Equiped with encoder ensures the accuracy and stability of bending.
Equiped with adjustable speed valve on pressure die ensures the synchronization of bending.
Water cooling system ensures the equipment long-time work stably under the high temperature.
CE&ISO 9001:2000
OPTIONAL of Tube Bender
Automatic pipe rotating(by servo motor) or Automatic pipe feeding(by servo motor)
Anti-clockwise bending
Extra mandrel length
Pipe punching function
PLC controlling
Tie rod bars on bending arm
Feeding length positioner
Mandrel lubrication function
Air cooling device
Cooling Conditioner
Safety mat
TOOL:
STANDARD MATERIAL: 45# STEEL
OPTIONAL MATERIAL:
Ampco Bronze- Mandrel&Wiper die for Stainless Steel Pipe
Nylon- Bending die,Clampe die&Pressure die for Aluminum Pipe
Cr 12-For other pipe material
ACCESSORIES:
TOOL,TOOL BOX, MANUAL OPERATION, INSTALLATION DVD, SPARE PART

TL-185 M-shaped tube bending machine, is an intelligent machine which can bend various shapes of tubes.

Functions:
1. 14 touch screen, operation instruction is attached.
2. PLC automatically controlled, change the parameters according to your requirement.
3. Servo motor controls bending and feeding, the speed, angle and length are all adjustable.
4. Pneumatic clamping, can bend 1½4pcs tubes at a time.

Main technical parameters:
1. Power supply: Single-phase 220V, 50Hz
2. Rated power: 4KW
3. Air supply: 5í½7kg/cm2
4. Applicable tube diameter: 6.0mmí½ª¦10mm
5. Size LxWxH:1650*900*1450 (mm)
6. Weight: 1000kg

With over 20 years of international experience, AH Machinery supplies a wide range of top-quality machinery made in Taiwan, including NC Hydraulic 4-Roll Tube Bending Machines, NC Hydraulic 4-Roll Plate Bending Machines, 4-Roll Plate Rolling Machine with Pre-Bending, NC Hydraulic 4-Roll Bending Machines, NC Hydraulic Four-Roll Bending Machines.
Customized specifications are available to meet your unique needs.

/SPECIFICATION/
- Capacity [mm]= 4x3100, 4x4100, 5x1580, 6x1300, 6x2050, 6x2550, 6x3100, 6x4100, 8x1580, 8x2050, 8x2550, 8x3100, 8x4100, 10x1270, 10x1300, 10x1580, 10x2050, 10x2550, 10x3100, 10x4100, 13x2050, 13x2550, 13x3100, 13x4100, 16x2050, 16x2550, 16x3100, 16x4100, 20x2050, 20x2550, 20x3100, 20x4100, 25x2050, 25x2550, 25x3100
25x4100, 30x2050, 30x2550, 30x3100, 35x2050, 35x3100
- Machine Tonnage [mm]= 4, 5, 6, 8, 10, 13, 16, 20, 25
- Length of Metal Sheets [mm]= 1270, 1300, 1580, 2050, 2550, 3100, 4100
- Main Motor [HP/KW]= 3/2.2, 5/3.7, 7.5/5.6, 10/7.5, 15/11.2, 20/14.9, 25/18.6, 30/22.4, 50/37.3, 75/55.9
- Diameter of Top Shaft [mm]= 120, 140, 160, 180, 190, 200, 210, 240, 250, 260, 280, 300, 320, 350, 380, 420, 460, 500
- Weight [Kgs/lbs]= 1850/4079, 2310/5093, 2500/5512, 2550/5622, 2800/6173, 3500/7716, 3600/7937, 4200/9259, 4500/9921, 4600/10141, 5100/11244, 700/12566, 6600/14551, 7600/16755, 7800/17196, 8100/17857, 8500/18739, 8900/19621, 9100/20062, 9900/21826, 10500/23149, 11000/24251, 11500/25353, 11800/26015, 12000/26455, 13000/28660, 13500/29762, 14000/30865, 15000/33069, 15500/34172, 16000/35274, 17000/37479, 18000/39683, 20000/44092, 21000/46297, 23300/51368, 25000/55116, 32000/70548, 35000/77162, 40000/88185
- Type= NC Hydarulic
- Roll= 4
- Pinch= Double
- For= Medium Duty

/STANDARD ACCESSORIES/
v NC Controller & Touch Screen
v Hardened Alloy Steel Rolls
v Movable Control Panel with Footswitch
v Hydraulic Drop-End
v Position Encoder
v Hydraulic Balancing System

/FEATURES/
#Customized_specifications_are_available.
#High_caliber_and_Accurate.

/FINAL PRODUCTS/
Metal Fabrication, Pressure Vessel Manufacturing, Pressure Vessels for Oil, Pressure Vessels for Gas, Forming Cylindrical Shells for Oil, Forming Cylindrical Shells for Gas, Tank Manufacturing, Shipbuilding, Create Curved for Ship Hulls, Create Curved for Other Ship Components, Rolling Plates for Ship Hulls, Rolling Plates for Other Ship Components, Pipeline Construction, Architectural Metalwork, Bridge Construction, Aerospace Industry, Bending for Aircraft, Fabrication of Components for Aircraft, Rolling Metal Plates for Aircraft, Bending for Aerospace, Fabrication of Components for Aerospace, Rolling Metal Plates for Aerospace, Wind Tower Manufacturing, Railroad Industry, Energy Sector, Automotive Industry, Pipe and Tube Manufacturing, Construction Equipment Manufacturing, Custom Metal Fabrication.

Welcome to contact us!
Contact us today for high-caliber and accurate machinery solutions.

Metal stamping dies, fine blanking dies, die-casting dies, plates, tubes, profiles, undercutting, punching, stretching, bending,

Multi-function Pipe Bending Machine

Model: SWG-2A
Max Pressure: 44Mpa
Max Movement: 250mm
Angle Of Curve Tube: 2
Curvature Radius:4D
Hydraulic Oil: N15
Pipe External Diameter Series D X T (mm): 21.3X2.75 26.7X2.75
33.5X3.25 42X3.25 48X3.5 60X3.5
Mould: 1/2", 3/4", 1", 1 1/4", 1 1/2", 2"
Gross Weight: 60 KGS

Packing: Size: 900*600*1100(mm).
