Premium Grade Flexible Trailing Cables

S.NO. Type
Indentification
Voltage Grade
Application
1. Flexible Trailing Cable
FT
1.1 KV Portable m/c
Coal cutlers and similar
2. Flexibke Trailing Cable
FTD
1.1 KV
Hand
3. Pliable Armoured Flexible Cable
P3
1.1 KV
Conveyors, Loaders and similar transportable m/c.
4. Pliable Armoured Flexible Cable
PC
1.1 KV
Remote Control Circuit
5. Pliable Armoured Flexible Cable
PL
1.1 KV
For Coal Face Light
1. FT
a) Ft3-5 core 5 Core around a cradle separator
b) FT4-5 core 3 Power cores with protective screen one unscreened plot clad around bare central conductor.
c) F 16-5 Core 3 Power Core with protective screen with plot core laid around an elastomeric centre. Cross section range : 16 to 95sq. mm.
2. FTD
a) FTD-3 core 3 Power core + pilot core + each core all 6 sq. mm. laid around cradle separatoe.
3. P
a) P3-5 Core 3 Power Core + pilot core + each core around cradle separator cross section 6 to 35 sq. mm.
4. PC
a) PC1-2 Core cross section 2.5 sq. mm. - 4 sq. mm.
b) PC2-3 Core cross section 2.5 sq. mm. - 4 sq. mm.
5. PL
a) PL1-4 Core cross section 4 sq. mm.
b) PL2-5 Core cross section 4 sq. mm.
