PWM Frequency: 40 K Hz
Solar Panel Maximum open circuit voltage: 25 volts.
Charge control Efficiency: Greater than 85 %.
Ambient Temperature: 0- 40 C.
Storage Temperature: 0-80 C.
Charge Controller Dimensions: 100 X 83 mm.
Protections:
Battery over charge Protection
Battery deep discharge Protection
PV reverse voltage Protection
Battery reverse voltage polarity protection
Load ON/OFF:
In the CC left corner there's a jumper.
If the jumper is plugged in the Load will turn OFF.
If the jumper is plugged out Load will turn ON
Indications:
Red LED: Indicates Battery low
Green LED: Indicates Charging and Battery full.
Yellow LED: Indicates Load ON/OFF
