Model PR-RP700
Max working width 700mm
Min working length 491mm
Working thickness 2-160mm
Feeding speed 5-30m/min
Abrasive belt size 730*1900mm
Total Motor power 39.94kw
Working air pressure 0.6Mpa
Air consumption 9m/h
Volume of dust collection device 8500m³/h
Overall dimensions 1363*2544*1980mm
Net weight 3000kg
This machine is used for polishing paper tube to make tube surface smooth, and coating wax on tube surface. The polished&wax-coated tubes are use for winding high quality winding materials. The machine is controlled by Mitsubishi PLC and inverter.
Part 1 Equipment introduction
The paper can assembly machine adopts advanced forming process, can complete a variety of forming processes, and can completely replace manual operation procedures.
The equipment has strong stability and high production efficiency, and can one-to-one operation,thus liberating labor force to a large extent.
The equipment has the advantages of saving raw materials and low energy consumption.
Stable structure operation,forming stable and low noise.
It is easier and faster to replace the mold.
Part 2 Advantage characteristics
Solving the problem of multi-manual operation in the traditional flat-bottomed paper can assembly process.
The equipment can automatically complete the labeling, inside curling, sealing, and scraping operations.
With high efficiency, high stability, high quality, assembly work high intelligence, can be unmanned operation and other performance characteristics.
Product Description
This machine is used for slitting and rewinding jumbo paper roll into small paper rolls with required width. It has auto. deviation correcting system, auto. tension control system, paper edge blower device, auto. paper loading/unloading system.2pcs air-expansion shaft will be delivered together with machine.
The machine owns below features:
Siemens PLC
WeiLun touching panel.
DuoChuan servo motor
SINNE Inverter
Auto. Tension controller
Taiwan Magnetic powder brake
8171 Industrial And Automotive Suppliers
Short on time? Let Industrial And Automotive sellers contact you.
Thermocouple assembling machine
The machine is used for assembling thermocouples automatically. It consists of paper tube delivering device, tube holding device, tube parting device, thermocouple Head delivering device, thermocouple assembling device, gluing device, thermocouple discharge device.
Technical Parameter:
Model SANTA-A
Paper Tube Length 300-1200mm
Paper Tube Inner Diameter 16-20mm
Paper Tube Outer Diameter 28-31mm
Thermocouple Assembling Speed 700-900pcs/hour
Power 1.5kw
Dimension 3300x2700x1300
This production line adopts polyethylene (PE) material extrusion machine for film coating. The PE material is absorbed to material canister by automatic drying and material absorbing device. Then the material would be melted, after filter, the melted PE is distributed evenly onto the T shape mould. And finally it can be coated onto base material evenly.
Features:
This is the advance model of PE coating machine. It has multi-extrusion mould, multi- working station, The coating and compouding can be done by one step.
Our machine are using Siemens PLC for easy setting and operation, all parameter can be set by the touch screen.
This machine is used for punching metal sheet into metal cover/lid. The produced cover/lid is used for making canisters. The machine is controlled by PLC and servo motor. 1 set of punching mold will be delivered together with machine. Extra mold needs extra payment.
MAIN SPECIFICATION
ModelSANYP-1000*1000
Punching pressure80T
Speed60times/min
Work table transverse&Longitudinal travel1000mm
Power3.7KW/380V/50HZ/3 phases
Weight~2500kgs
Dimension1600mmX1200mmX800mm
1.Introduction:
This machine is used for punching on paper tube. It is easy operate and efficient.
This is the website about how it works:https://youtu.be/adTehQmLLuI
Main features
ModelSANPTD-152
Tube diameter50-200mm
Tube thickness3-30mm
This machine is used for slitting and rewinding jumbo paper roll into small paper rolls with required width. The small paper rolls are used to produce edge protector, paper tube etc.It has automatic blade position adjustment , edge blowing device, edge correcting controller and hydraulic paper loading/unloading system.1 pieces of pneumatic core shafts will be delivered together with machine.
The machine owns below features:
Mitsubishi PLC and Inverter.
Mitsubishi touching panel.
Mitsubishi MT40 Tension controller
Mitsubishi Detector
Taiwan Magnetic powder brake
Main specification:
Model:SANJSR-02
Jumbo roll max.width :1600mm
Jumbo roll max.diameter:1500mm
Jumbo roll core diameter:76.2mm
Finished roll min.width:50 mm
Finished roll max.diameter:1300mm
Paper range:50~700gsm
Speed:Max 250m/min
Blade:20 pairs
Power:7.5KW/380V/50HZ/3 phases
Weight:~3000kgs
Dimension:Unwinder:2000mm*3500mm*1200mm,
This machine is used for slitting and rewinding jumbo paper roll into small paper rolls with required width. The small paper rolls are used to produce edge protector, paper tube etc.It has automatic blade position adjustment , edge blowing device, edge correcting controller and hydraulic paper loading/unloading system.1 pieces of pneumatic core shafts will be delivered together with machine.
The machine owns below features:
Mitsubishi PLC and Inverter.
Mitsubishi touching panel.
Mitsubishi MT40 Tension controller
Mitsubishi Detector
Taiwan Magnetic powder brake
Main specification:
Model:SANJSR-02
Jumbo roll max.width :1600mm
Jumbo roll max.diameter:1500mm
Jumbo roll core diameter:76.2mm
Finished roll min.width:50 mm
Finished roll max.diameter:1300mm
Paper range:50~700gsm
Speed:Max 250m/min
Blade:20 pairs
Power:7.5KW/380V/50HZ/3 phases
Weight:~3000kgs
Dimension:Unwinder:2000mm*3500mm*1200mm,
This machine is a fully automatic paper cone production line for textile industry. It consists of paper cone winding unit, cone drier, and paper cone finishing unit. The complete production process:Jumbo paper reel feedingInside and outside printingPaper edge grindingpaper cuttingpaper cone winding&trimming Paper cone dryingUnfinished products collectingHead curling(Bull nosing)Grinding V-shaped notchingLine pressingFinal products collecting. One set of cone mold will be delivered together with the machine. Extra mold needs extra payment.
Configurations&Features
-- Controlled by Delta PLC, Delta Inverter, and Delta touching panel
-- Paper cutting driven by Taiwan Airtac cylinders. Durable&Easy adjustment
-- Paper patterns delivered by Precision linear module driven by servo motor. High-precision& Long service life
-- Sucking paper on spindle by Japan Orion vacuum pump. Long service time
-- Cone winding driven by Delta servo motor. Rolling circle can be set freely. Winding tightly.
-- New vertical type cone finishing machine: Simple machine, not complex. Machine runs very stably. Easy operate, less maintenance. Only a few of parts need to be changed when cone size changes.
-- If you need to produce different size cone, only need to change 2pcs mold and adjust the position of paper cutting blades. Very easy and convenient.
INTRODUCTION
This machine is used for making round top & bottom lid for paper drum.
specification
Model:SANLM-450
Paper Tube Diameter: Ï?280mm-Ï?500mm
Function: making round top&bottom lid for paper drum..
Speed:70pcs/hour
Motor Power: 1.1KW/380V/50HZ/3Phase
Weight: ~400KG
1. Introduction:
The machine is used for producing parallel paper drums automatically. It consists of paper stand, gluing device (automatic cycle system with gear pump), paper cutting device, tube/drum winder, drum cutting device, tube/drum discharging device. This machine vacuum-absorbs paper on mandrel automatically. The mandrel is retractable/collapsible mandrel which will make drum discharging easily from mandrel. The machine is controlled by Siemens PLC, Touching panel and Delta inverter. One mandrel is with machine. Extra mandrel needs extra payment.
2. Technical parameter:
Model: SANPT250-650
Size of jumbo paper roll: 850mmx1300mm (Width*Dia.)
Paper drum length: 850mm
Paper drum inner diameter: 250mm-650mm
Paper drum thickness: Normal 1.5-10mm. (Operator can set it according to actual need.)
Paper grammage: 200-550gsm
Production speed: ~1800pcs/shift(8hours)(The more diameter and thickness, the lower production speed.)
Number of knife: 3pcs
Power: 7.45KW/380V/50HZ/3Phases
Dimension: 3200X2600x1500mm
Introduction
This machine is used for curling edge for paper drum.
Specification
Model:ZDJB-450
Paper Tube Diameter: Ï?280mm-Ï?450mm
Speed :120pcs/hour
Motor Power:3.3KW/380V/50HZ/3Phase
Weight: ~800KG
Introduction
This machine is used for seaming bottom and curling edge for paper drum.
Specification:
Model FD-600
Paper Tube Diameter Ï?350mm-Ï?600mm
Speed 60pcs/hour
Motor Power 4KW/380V/50HZ/3phase
Weight ~1500KG
Introduction
This machine is used for gluing the cover and bottom through pressure.
Specification:
Model YD-450
Paper Tube Diameter Ï?280mm-Ï?450mm
Speed 40pcs/hour
Motor Power 5.0KW/380V/50HZ/3Phase
Weight ~700KG
Introduction:
This machine is used for curling drum top automatically.
Specification:
Model ZDJB-450
Paper Tube Diameter Ï?280mm-Ï?450mm
Speed 120pcs/hour
Motor Power 3.3kKW/380V/50HZ/3Phase
Weight ~800kg
Introduction:
This machine is used for rolling wrinkles at the top and bottom of drum body and cover.
Specification:
Model:GB-450
Paper Tube Diameter:Ï?280mm-Ï?450mm
Speed:100pcs/hour
Motor Power:0.55KW/380V/50HZ/3Phase
Weight: ~180KG
