Main Technical Features
Technical Detail Value
Product Name Apex Eco 11 kW Smart Inverter
Output Power 11,000 Watt (11 kW)
Working Voltage 48V DC
MPPT Solar Charge Current 120A
PV Input Voltage 120V - 500V
AC Output 220V -Pure Sine Wave
Battery Compatibility Gel, AGM, Lithium (LiFePO4)
No Grid Connection (Off-Grid Only)
Display LCD digital display
Cooling Automatic fan control
Protection Systems Overload, short circuit, over temperature, low voltage etc.
Waranty 2 years
Single Phase
Technical Specifications
Np Power 6.2 kW Off-Grid Smart Inverter
Nominal Output Power 6200 Watt
Output Waveform Pure Sine Wave
Output Voltage 230V
Output Frequency 50Hz-60Hz
Efficiency 94%
Max. Charge Current 120A
Max. PV Charge Current 100A
Max. AC Charge Current 60A
Dc Input Voltage 24V DC
Rated Power 6500 Watt
Max. PV Input 500V DC
Working Temperature -15 -60 Degrees
Dimensions 358*295*105 - 8.7 KG
2 Year Warranty
Single Phase
Technical Specifications
Feature Description
Maximum Power 6.2 kW (6200 Watt)
System Voltage 48V DC
MPPT Solar Charge Controller 120A (Wide Input Voltage Range)
Waveform Pure Sine Wave
AC Output Voltage 220-230V (�±%2)
Input Voltage (PV) 120V - 500V DC
Smart Modes Solar Priority / Battery Priority / Grid Priority
Sales to Grid Yes (On-Grid Hybrid Mode)
Display Large LCD screen + detailed menu
Protection Features Overload, short circuit, high temperature, low battery etc.
APEX Eco Series 5.5 kW 48V MPPT Off-Grid Smart Inverter Get Your Power From the Sun!
Manage Solar Energy with Smart TechnologyThe Apex Eco 5.5 kW inverter is specifically designed for 48V battery systems, featuring MPPT (Maximum Power Point Tracking) technology, pure sine wave output, high performance, and off-grid operation. This device efficiently utilizes the energy obtained from solar panels to both charge batteries and supply your electrical appliances with 220V AC power.
It is an ideal energy management solution for agricultural lands, country houses, caravans, container buildings, and tiny house projects.
What is the Apex Eco 5.5 kW Inverter?This product acts as the brain of the solar panel + battery + inverter system. Thanks to the high-efficiency MPPT solar charge controller on board, it maximizes the use of solar energy. The 48V system voltage results in lower current, reducing cable losses, thereby enabling a safer and more economical system setup.
What Does the Apex 5.5 kW Inverter Do?
Converts solar energy into electricity
Efficiently charges batteries
Provides power for off-grid living spaces
Has the capacity to run high-power devices
Offers a large LCD screen to view all system parameters
Where Is It Preferred?The Apex 5.5 kW smart inverter is frequently preferred in the following applications:
Solar-powered home systems
Tiny house energy systems
Caravan electrical infrastructure
Agricultural irrigation and equipment electrificatio
Uninterruptible power supplies for security systems
Technical Specification
Battery (Off-Grid) and Batteryless (On-Grid) operation
Nominal Output Power 8500 Watt
Output Waveform Pure Sine Wave
Output Voltage 230V
Output Frequency 50Hz-60Hz
Efficiency 94%
Dc Input Voltage 48V DC
Mppt 120A
Rated Power 10000 Watt
Maximum PV Input 500V DC
Working Temperature 10-55 Degrees
Dimensions 450*300*130
Weight 9.6 KG
Paralleling Feature
Communication Port
2 Year Warranty
Maximum Output Power: 6.2 kW output capacity, enough to power all your electrical devices in homes, offices, caravans, cottages, villas, and tiny houses.
Voltage Compatibility: Operates with 48V DC battery systems.
Built-In MPPT Charge Controller: Offers up to 98% charging efficiency, directing solar energy to batteries in the most efficient way.
Smart Display & Menu: Advanced LCD screen allows real-time monitoring of system voltage, charging status, load, and other parameters.
Pure Sine Wave Output: Fully compatible with sensitive electronic devices.
Multiple Protection Systems: Protects against overvoltage, short circuits, overheating, and undervoltage.
AC or Generator Charging Support: Can charge batteries from an external AC source, ensuring uninterrupted power.
Low Standby Power Consumption: Contributes to energy savings.
Durable and Compact Design: Heat and impact-resistant casing ensures long-lasting use.
Commercial businesses requiring backup power (small shops, clinics, workshops, etc.)
Why Choose NP Power?
Backed by 12 years of Electrozirve engineering experience, NP Power inverters offer reliable energy solutions with wide functionality, high efficiency, professional support, and a user-friendly interface.
Technical Specifications
Np Power 3.5 kW Off-Grid Smart Inverter
Nominal Output Power 3500 Watt
Output Voltage 230V
Output Frequency 50Hz-60Hz
Efficiency 94%
Max. Charge Current 100A
Max. PV Charge Current 100A
Max. AC Charge Current 60A
Dc Input Voltage 24V DC
Rated Power 4000 Watt
Max. PV Input 500V DC
Working Temperature -10-55 Degrees
Dimensions 330*278*98 4.4 KG
2 Year Warranty
The APX Pro 4.2 kW Hybrid Smart Inverter is an advanced solution developed to deliver maximum efficiency in both off-grid and on-grid solar power systems. Operating at 24V DC, this inverter can run without batteries, allowing your system to function solely with solar panels or directly transfer energy to the grid. This not only saves energy but also provides an opportunity to earn income through net metering.
High Voltage Support and Broad Compatibility
With a 500V DC input capacity, the device qualifies as a high-voltage inverter, enabling longer panel strings. This reduces installation costs and increases system flexibility. Its advanced lithium battery communication support ensures full compatibility with LiFePO4 and other smart battery types, making battery management safer and more efficient.
Smart Control and Remote Access
With the optional WiFi module, you can monitor your inverter remotely and track your energy production data in real time via mobile devices. The advanced monitoring features make it easy to analyze your system's performance.
Key Features:
24V DC system support Battery-free operation (PV Load / PV Grid) Grid-tied energy export capability (net metering compatible) 500V DC high-voltage solar input
Lithium battery communication support
Optional WiFi connectivity
Advanced MPPT solar charge control Easy installation and user-friendly interface
Application Areas: Residential solar energy systems, camper and caravan systems, commercial enterprises, agricultural irrigation systems, and projects for energy export
